Telecomando EC60-410-0

View larger

Telecomando EC60-410-0

Telecomando su misura composto da 2 pannelli assemblati su un pezzo in forma di U con coperchio avvitato. Il coperchio è rimovibile con un cacciavite.

Scheda tecnica

MODELLI	Contenitore mano EC60-8xx
TIPOLOGIA COSTRUZIONE	Telecomandi su misura composti da 2 pannelli assemblati su un pezzo in forma di U con coperchio avvitato. Il coperchio è rimovibile con un cacciavite.
